datasheet HKS-D

Product-Description

High pressure ball valve HKS-D

Stainless steel

With Steck-O connector

DN 38(40)-80

PN max. 145

Series

15 – female - male connector
16 – female - female connector

Temperature range

Standard: -10°C to +90°C
On request: -50°C to +230°C

Range of use

Liquids: Liquids group 1 and 2 according to PED 2014/68/EU Article 13
Gases: Liquids group 1 and 2 according to PED 2014/68/EU Article 13
As a matter of principle, the resistance to the flow medium must be ensured.

Technical specification

HKS-C and HKS-D ball valves are designed as ball valves with fixed female connector. The stem is fitted blowout-proof. Fast fitment in suitable HD line systems is possible by means of the male/female connection variant.

Please ask separately, where requirements exceed the standard conditions of use listed in this data sheet. As a matter of principle, the operating and maintenance instructions, in particular the safety instructions must be observed! Operating and maintenance instructions as well as the approval certificates can be downloaded at www.von-scheven.de.
We reserve the right to carry out technical modifications.
